Microchip Technology extends mTouch™ technology to include projected capacitive touch-screen sensing
		Microchip has announced the availability of mTouch™ Projected Capacitive Touch-Screen Sensing Technology, the first in a series of patent-pending releases supporting projected capacitive touch-screen solutions across the company’s portfolio of 8-, 16- and 32-bit PIC® MCUs. The technology announcement is supported by the release of the mTouch Projected Capacitive Development Kit, featuring the first device to implement the technology; the 8-bit PIC16F707.

Key Facts:

• Microchip adds multi-touch and gesture sensing through projective capacitive technology
• New technology supported by Projected Capacitive Development Kit – available now
• First device to feature projected capacitive sensing is low-cost 8-bit PIC16F707

Projected capacitive touch sensing extends resistive and existing capacitive touch sensing technology to include multi-touch and gesture sensing, enabling users to implement robust glass-front user interfaces that simplify user interaction. Typical applications include global positioning systems, thermostats, mobile handheld units and other devices that use smaller displays with a finger input. The technology is available via a royalty free source code license from Microchip’s online Touch Sensing Design Center (http://www.microchip.com/get/AX10).

The mTouch Projected Capacitive Development Kit (part No DM160211) includes a 3.5” sensor mounted on a sensor board, a projected capacitive board with the PIC16F707 MCU and fully functional firmware. The open source code supports sensors with up to 32 channels and the kit includes a Graphical User Interface tool that enables easy parameter adjustment.

The PIC16F707 features two 16-channel Capacitive Sensing Modules (CSMs) that can run in parallel for increased sampling speed, and operates from a wide input voltage range of 1.8 – 5.5V, with a typical projected capacitive sensor application operating current of 1.5mA at 5V. The PIC16F707 is available in volume today.

For more information, or details on the full range of Microchip products available from Anglia, please call +44 (0)1945 474747 or email info@anglia.com
