Ultra-broadband capacitor series from AVX minimizes insertion and return loss

AVX has developed a broadband capacitor that addresses DC blocking issues from 16kHz (-3dB roll-off) to 40GHz by providing low insertion and return losses. This multilayer capacitor uses patented precision thin film termination process to maximize board space in DC blocking applications.

The broadband capacitor is ideal for applications such as semiconductor data communications, receiver optical subassemblies, trans-impedance amplifiers and test equipment. Designed utilizing AVX’s patented precision termination process, the GX Series ultra-broadband capacitor is completely orientation insensitive with a standard EIA 0402 footprint to minimize board space requirements, and is available with X5R or X7S dielectric characteristic.

“AVX’s patented thin film termination process enables the ultra low insertion and return loss values that the GX Series ultra-broadband capacitor provides customers,” said Larry Eisenberger, AVX Senior Technical Marketing Engineer. “We are working to expand the current product offering to include additional case sizes and increase the operating range.”

Both nickel-gold and nickel-tin terminations are available to cover a wide range of attachment processes. All GX Series parts are RoHS compliant.

Click here to view the data sheet.

For more information, or details on the full range of AVX products available from Anglia, please call +44 (0)1945 474747 or email info@anglia.com

Alternatively, click on this link to go to the main AVX section where you can view other news articles and product data.
