New space saving washable IP67 rated rotary coding switches from Knitter-Switch

Knitter-Switch has announced a new series of rotary coding switches that will interest designers of industrial and building automation systems and measuring instruments. They are washable, rated to IP67 and provide a contact breaking capacity of 100mA @ 42V. The new DRS/SMR 15000/16000 series of rotary coding switches are available with a PCB space saving body of just 7 x 7mm and offer surface mount and through-hole mounting versions.

Both designs can be reflow soldered. The surface mount version is supplied in tape and reel packing for pick and place assembly systems and also available with a shaft. Operating temperature range is -50ºC to +125ºC. Coding options include BCD 10 position and hexadecimal 16 positions, each available with both real and inverse (complement) coding.

For more information, or details on the full range of Knitter-Switch products available from Anglia please call +44 (0)1945 474747 or email info@anglia.com

Alternatively, click on this link to go to the main Knitter-Switch section where you can view other news articles and product data.
