New AVX parts retain voltage and capacitance performance of thicker parts

AVX Corporation has developed a series of ultra thin ceramic capacitors targeted at applications where low profile is vital, such as smart cards, high-density SIM cards, and memory modules.

Designated the UT Series, the ultra-thin parts have the same footprint as 0402 devices, but are only as thick as conventional 0201 products. In addition, the advanced capacitors retain the same voltage and capacitance ratings as the standard 0402 capacitors.

Featuring a novel chemical termination system that allows very precise and highly repeatable termination thickness and dimensions, parts can be produced that measure just 0.3mm high with a capacitance value of 10nF and a voltage rating of up to 25V. Operating temperature is -55 to +85degC. Insulation resistance is 100 000MΩ minimum. ESL is 164pH; ESR is 75.6mΩ.

"Our customers have recognized the dimensional benefits that our patented termination process brings," said Radim Uher, AVX Product Marketing Manager. "These new ultra-thin ceramic capacitors suit applications anywhere the thickness of components is major hurdle in the design. Later we also expect to introduce even thinner 0.15mm devices for embedding within PCBs, saving even more space."

Click here to view the UltraThin datasheet.

For more information, or details on the full range of AVX products available from Anglia, please call +44 (0)1945 474747 or email info@anglia.com
