AVX develops the industry’s smallest 0.4mm pitch
board-to-board connector

Designated the 5802 Series, the low-profile 10 to 60 position connector family is ideal for portable devices due to their unique design that combines ultra-small size with high-reliability.

The area beneath the 5802 Series connector is fully insulated, allowing designers to run tracks beneath the device for a more flexible board layout. To ensure low insertion force while maintaining high retention and separation force, the connector contact employs a twin rib structure. The structure also ensures that contacts are wiped clean from contaminants, such as dust and flux, during every mating cycle.

“Our 5802 low-profile board-to-board connector series is ideal for portable devices due to its unique design that combines ultra-small size with high-reliability,” said Mark Jarman, KEC Product Manager at AVX. “The space-saving design allows engineers to be flexible in their design without sacrificing performance or ruggedness that end consumers demand.”

Providing an audible and tactile “click” mating, the plugs are shaped by insert moldings and enclosed metal fittings on the receptacles to improve breaking strength against any drop impact. A nickel barrier and solder-on receptacle contacts prevent solder wicking, while pinched-type dual contacts further enhance contact reliability.

Other specifications include 0.3A rated contact current, 50 V rated contact voltage, gold plated beryllium copper contacts, UL94V-0 heat-resistant insulator material, and -40 to 85degC operating temperature.

The AVX 5802 Series connectors are ideal for use as a low profile and space efficient board-to-board connector that is required for internal wiring of mobile devices, such as cell phones, MP3 players, digital still and video cameras, PDAs, and game players. The connectors are also suitable for connecting LCDs in camera modules, CMOS/CCD image pickup devices, and other space-sensitive board applications.

For more information, or details on the full range of AVX products available from Anglia, please call +44 (0)1945 474747 or email info@anglia.com
